01.4IB.46300

Tables

Table A Horsepower, Current, and Voltage Ratings .......................................................11

Table B Voltage and Interrupting Ratings of Class E2 Medium Voltage Controllers .....11

Table C General Guideline for Outgoing Feeder Cables .................................................24

Table D Bolt Torque Values for FlexTrol™ .........................................................................................26

Table E Bus Wrapping Components ................................................................................ 26

Table F Insulation of Bus Bar ...........................................................................................27

Table G Insulation of Single Bus Bar Connection Joint ..................................................27

Table H Insulation of Double Bus Bar Connection Joint .................................................28

Table I Insulation of Tee Connection Joint ...................................................................... 28

Table J Insulation of Dead End Bus Bar Joint .................................................................29

Table K Eaton Publication References ............................................................................42

Table L Medium Voltage Vacuum Contactor Eaton 400A SL

Renewal/Replacement Parts .............................................................................48

Table M Medium Voltage Vacuum Contactor Eaton 800A SL

Renewal/Replacement Parts .............................................................................49

Table N R-Rated Clip-On Fuses for 400A Contactor ........................................................50

Table O R-Rated Bolt-On Fuses for 800A Contactor .......................................................51

Table P E-Rated Clip-On Fuses for 400A Contactor ........................................................52

Table Q E-Rated Bolt-On Fuses for 800A Contactor .......................................................52

Table R Control Relays .....................................................................................................53

Table S Current Transformers .........................................................................................53

Table T Ground Current Transformers ............................................................................53

Table U Control Power Transformers - SNC ....................................................................54

Table V Control Power Transformer Primary Fuses ........................................................ 54

Powell FlexTrol Class E2 User Manual
