2.7 Safety devices
DANGER!
Malfunctioning safety devices may pose a fatal
risk!
Safety devices must be intact and properly integrated
into the control unit's configuration and software in
order to guarantee safety.
n Before initial commissioning of the machine, ensure that all
safety devices are fully functional and correctly installed.
n Ensure that safety related inputs/outputs of the PAMIO compo-
nents and the CNC control unit are fully functional and perform
as intended.
n Never disable safety devices.
n Heed regulations concerning hardwiring of safety circuits.
Superior CNC Control unit or PLC
For information on required connections between the
PA control unit and safety devices integrated into the
CNC machine see the documentation provided by the
machine's manufacturer.
Safety connector
For information on the safety connector's purpose,
specification and wiring see
Ä
Chapter 3.6 “Safety
connector” on page 55,
Ä
Chapter 2.8 “Machine
safety” on page 17 and
Ä
Chapter 5.4 “Wiring for
machine safety” on page 81.
Data safety
For information on data safety see
Ä
Chapter 2.10
“Data safety” on page 20.
2.8 Machine safety
For information regarding the safety connector's specification and
wiring examples see
Ä
Chapter 3.6 “Safety connector” on page 55
and
Ä
Chapter 5.4 “Wiring for machine safety” on page 81.
Safety
Superior Control Units
Safety Connector
Software
Additional Information
PA 8000 EL CNC control unit
Safety
24.09.2015 | 17
