8.2.1 Module 2416 EL LEDs

The 2416 EL module has four LEDs for diagnostic purposes.

Fig. 47: Status LEDs

1 Status

2 Access

3 Bustest

4 Monitor

The LEDs' states are assigned the following status messages:

Overview

PA 8000 EL CNC control unit

Troubleshooting

24.09.2015 | 91
