Feature Value Specifications
digital inputs 24 (3 bytes) 24 V DC
digital outputs 16 (2 bytes) 24 V DC
isolation optical
Feature Value Specifications
encoder inputs 4
analog inputs 4 +/- 10 V (12 bit)
analog outputs 4 +/- 10 V (16 bit)
Feature Value Specifications
encoder inputs 2
analog inputs 4 +/- 10 V (10 bit)
analog outputs 4 +/- 10 V (16 bit)
termination plug integrated
Feature Value Specifications
digital outputs 2 24 V DC
The main characteristics for the digital inputs and outputs of the
PAMIO 2416 are similar to the ones of the integrated 2416EL mod-
ules (see
Ä
Chapter 3.3 “Module 2416 EL” on page 28).
For detailed information about PAMIO modules, their
installation and electric requirements refer to the PA
Accessories installation manual.
PAMIO 2416
PAMIO 4ENC4A
PAMIO 2ENC4A
PAMIO PWM
Characteristics
PA 8000 EL CNC control unit
Design and function
24.09.2015 | 63
