All PC connectors (PS2, VGA, USB, etc.) and some CNC
connectors (X13/X19) are located on the top side.
n Ensure that there is clearance of at least 100 mm (4 inches) to
allow accessibility to the connectors.
The PC connectors are shown as examples, and can vary from
case to case.
On the bottom side of the control unit (opposite to PC connectors)
is a grid for the air inlet.
n Ensure, that there is clearance of 40 mm (1.6 inches) at min-
imum for air circulation.
The cabinet fan provides internal air circulation for the control unit.
Its proper operation is a prerequisite for safe operation of the con-
trol unit.
n Ensure that there is clearance of at least 30 mm (1.2 inches)
next to the fan's exhaust.
n Install an additional fan inside the cabinet, directed toward the
control unit.
Top / Bottom Spacing
PA 8000 EL CNC control unit
Installation
24.09.2015 | 77
