Power integrations InnoSwitch3 User Manual

Rev. A 10/18
14
Application Note AN-72
www.power.com
Figure 11. Continuation of Multiple Output Parameters Section of InnoSwitch3 PIXls Spreadsheet.
143
OUTPUT 2
144 VOUT2 0.00 V Output 2 voltage
145 IOUT2 0.00 A Output 2 current
146 POUT2 0.00 W Output 2 power
147 IRMS_SECONDARY2 0.00 A
Root mean squared value of the secondary
current for output 2
148 IRIPPLE_CAP_OUTPUT2 0.00 A
Current ripple on the secondary waveform for
output 2
149 AWG_SECONDARY2 0 AWG Wire size for output 2
150 OD_SECONDARY2_INSULATED 0.000 mm
Secondary winding wire outer diameter with
insulation for output 2
151 OD_SECONDARY2_BARE 0.000 mm
Secondary winding wire outer diameter without
insulation for output 2
152 CM_SECONDARY2 0 Cmils
Bare conductor effective area in circular mils for
output 2
153 NSECONDARY2 0 Number of turns for output 2
154 VREVERSE_RECTIFIER2 0.00 V
SRFET reverse voltage (not accounting parasitic
voltage ring) for output 2
155 SRFET2 Auto NA SRFET selection for output 2
156 VF_SRFET2 NA V SRFET on-time drain voltage for output 2
157 VBREAKDOWN_SRFET2 NA V SRFET breakdown voltage for output 2
158 RDSON_SRFET2 NA mΩ
SRFET on-time drain resistance at 25degC and
VGS=4.4V for output 2
159
160 OUTPUT 3
161 VOUT3 0.00 V Output 3 voltage
162 IOUT3 0.00 A Output 3 current
163 POUT3 0.00 W Output 3 power
164 IRMS_SECONDARY3 0.00 A
Root mean squared value of the secondary
current for output 3
165 IRIPPLE_CAP_OUTPUT3 0.00 A
Current ripple on the secondary waveform for
output 3
166 AWG_SECONDARY3 0 AWG Wire size for output 3
167 OD_SECONDARY3_INSULATED 0.000 mm
Secondary winding wire outer diameter with
insulation for output 3
168 OD_SECONDARY3_BARE 0.000 mm
Secondary winding wire outer diameter without
insulation for output 3
169 CM_SECONDARY3 0 Cmils
Bare conductor effective area in circular mils for
output 3
170 NSECONDARY3 0 Number of turns for output 3
171 VREVERSE_RECTIFIER3 0.00 V
SRFET reverse voltage (not accounting parasitic
voltage ring) for output 3
172 SRFET3
Auto
NA SRFET selection for output 3
173 VF_SRFET3 NA V SRFET on-time drain voltage for output 3
174 VBREAKDOWN_SRFET3 NA V SRFET breakdown voltage for output 3
175 RDSON_SRFET3 NA mΩ
SRFET on-time drain resistance at 25degC and
VGS=4.4V for output 3
176
177 PO_TOTAL 20.00 W Total power of all outputs
178 NEGATIVE OUTPUT N/A N/A
If negative output exists, enter the output number;
e.g. If VO2 is negative output, select 2
