Power Master PM-2500 - Specification; Technical Specifications

19
10. SPECIFICATION
MODEL 1200i 1500i 1800i
GENERATOR
Type Inverter Generator
AC Voltage
50Hz 100, 230V, 240V
60Hz 100, 120V, 240V
Max. Output 1.2 kVA 1.5 kVA 1.8 kVA
Rated Output 1.0 kVA 1.2 kVA 1.5 kVA
Power Factor 1.0
DC Output 12V / 4.0A
ENGINE
Model XY147F
Type Air-cooled, 4 cycle, OHC, Gasoline Engine
Bore×Stroke mm×mm 47×41.5
Displacement 72 cc
Max. Output 2.1KW / 5500rpm
Fuel Regular Automobile Gasoline
Fuel tank Capacity 3.6 liters
Rated Continuous Operation 4.3 hr 4.3 hr 4.0 hr
Lubricating oil SAE 10W30
Lubricating oil Capacity 0.60 liter
Starting System Recoil Starter
Ignition system C.D.I.
Spark Plug: Type A7RTC or CR5HSB (NGK)
DIMENSION
Net dimension L×W×H
492×262×406
Overall dimension L×W×H
525×295×440
Net Weight 18.5 Kg 18.5 Kg 18.5 Kg
Dry Weight 20.5Kg 20.5Kg 20.5Kg
z Specifications subject to change without prior notice.
