Istruzioni per l’uso e manutenzione
Cod. OQ7.5ARG114 – GB
Emiss. 19-01-11 Rev. 0 - Agg. /
9
POWER SYSTEM SRL
Via dell’Emigrante, 11/13 - 36040 Brendola (VI) Itali
2.1 CE MARKING
The CE marking (FIG. 1) certifies the conformity of the compressor with the essential safety and health requirements contemplated by
the European Directives listed in the EC declaration of conformity.
It is an adhesive label made of silver coloured polyester with printing in black, with the following dimensions: L = 95 mm - H= 120
mm. It is applied on the outside, on the rear of the compressor. The following data are indicated legibly and indelibly on the plate:
• The logo, name and address of the manufacturer
• The CE mark
• The model
• The serial number
• The max. working pressure (bar)
• The voltage and frequency of the electric power supply (V / Hz)
• The nominal power (kW)
• The weight (kg)
• The year of manufacture
Left side
Fig.1 (CE marking)
