Powerex SE Series User Manual

Scroll Enclosure Air Compressor 15-60 HP
Operating & Maintenance Manual
Powerex • 150 Production Drive • Harrison, OH 45030 • USA
P 1.888.769.7979 • F 513.367.3125 • www.powerexinc.com
IN596202AV • 21 February 2023
Page 3 of 32
Breathable Air Warning
This unit is NOT equipped and should NOT be used
“as is” to supply breathing quality air. For any application
of air for human consumption, you must t the air
compressor with suitable in-line safety and alarm
equipment. This additional equipment is necessary
to properly lter and purify the air to meet minimal
specications for Grade D breathing as described in
Compressed Gas Association Commodity Specication
for Air, OSHA, ANSI and/or Canadian Standards
Associations (CSA).
When the SE series compressor unit is used as part
of an appropriately congured Medical Air System,
meeting all requirements of NFPA 99, it is safe to utilize
as a breathing air source.
DISCLAIMER OF WARRANTIES
IN THE EVENT THE COMPRESSOR IS USED FOR
THE PURPOSE OF BREATHING AIR APPLICATION AND
PROPER IN-LINE SAFETY AND ALARM EQUIPMENT IS
NOT SIMUTANEOUSLY USED, EXISTING WARRANTIES
ARE VOID, AND POWEREX DISCLAIMS ANY LIABILITY
WHATSOEVER FOR ANY LOSS, PERSONAL INJURY OR
DAMAGE.
3. Only persons well acquainted with these rules of
safe operation should be allowed to use the compressor.
4. Keep visitors away and NEVEr allow children in the
work area.
5. Wear safety glasses and use hearing protection
when operating the unit.
6. Do not stand on or use the unit as a handhold.
7. Before each use, inspect compressed air system
and electrical components for signs of damage,
deterioration, weakness or leakage. Repair or replace
defective items before using.
8. Check all fasteners at frequent intervals for proper
tightness.
Motors, electrical equipment and
controls can cause electrical arcs that will ignite a
ammable gas or vapor. Never operate or repair in or
near a ammable gas or vapor. Never store ammable
liquids in gases in the vicinity of the unit.
Never operate compressor pump
without a protective guard. This unit can start
automatically without warning. Personal injury or
property damage could occur from contact with moving
parts.
9. Do not wear loose clothing or jewlery that will get
caught in the moving parts of the unit.
Surface may be hot even if unit is
stopped.
10. Keep ngers away from a running unit; fast moving
and hot parts will cause injury and/or burns.
11. If the equipment should start to vibrate abnormally,
STOP the unit and check immediately for the cause.
Vibration is generally a warning of trouble.
12. To reduce faire hazard, keep unit exterior free of oil,
solvent, or excessive grease.
An ASME code safety relief valve with
a setting no higher than the tank maximum allowable
working pressure MUST be installed in the air lines or in
the tank of any compressor. The ASME safety valve must
havesucient ow and pressure ratings to protect the
pressurized components from bursting.
Model HP
Standard Pressure Models
SCFM @ 100 PSIG
High Pressure
Models
SCFM @ 145 PSIG
Voltage
Sound Level dB(A)
Standard / High Pressure
Discharge
Connecon
Discharge Air
Approach Temp
SED15B 7.5 (2) 46.2 34 208/230/460 63 / 63 1” NPT 20°F
SED20B 10 (2) 62.4 49 208/230/460 64 / 66 1” NPT 22°F
SET225 7.5 (3) 69.3 51 208/230/460 65 / 65 1” NPT 25°F
SET30B 10 (3) 93.6 73.5 208/230/460 66 / 69 1” NPT 25°F
SEQ40B 10 (4) 125 98 208/230/460 66 / 69 1 ¼” NPT 22°F
SEH45B 7.5 (6) 139 102 208/230/460 66 / 66 1 ¼” NPT 24°F
SEP50B 10 (5) 156 122.5 208/230/460 67 / 70 1 ¼” NPT 24°F
SEH60B 10 (6) 187 147 208/230/460 69 / 72 1 ¼” NPT 25°F
