13 2000Wi OM
4. OPERATING INSTRUCTIONS
4.1 Starting the engine
When starting the generator after adding fuel for the first time or after long term storage,
or after running out of fuel, turn the fuel valve to the ON position, then wait for 10 to 20
seconds before starting the engine.
Before starting the engine, disconnect any load from the AC receptacles.
1. Turn the fuel valve lever to the “ON” position.
2. If the fuel tank was empty it may be necessary to pump the primer bulb 15 to 20 times to get fuel to the
carburetor.
3. Push the engine switch on the control panel to the “ON” position.
4. Move the choke lever to the “START” position.
5. Pull the starter grip lightly until resistance is felt, then pull briskly out.
6. Move the choke lever to the “RUN” position after the engine warms up.
Do not allow the starter grip to snap back. Return it slowly by hand.
Do not let the starter rope rub against the generator body or the rope will wear out
prematurely.
