PRELIMINARY STEPS
Open the package, then take out the device.
a) Remove the protective foil and transport protection (if any).
b) Check if the package contains dismantled parts and keys.
c) Check that the machine and accessories have not been damaged during transport.
d) Retain the packaging.
WARNING! The device and packaging are not for fun! Keep out of the reach of children, risk of swallowing or
suffocation.
DEVICE ASSEMBLY AND OPERATION
HANDLE ASSEMBLY AND ADJUSTMENT
1) Loosen this screw and adjust the height of this part to adjust the length underwater. It is important to ensure
that the lower unit is submerged at least 25mm when adjusting the depth of the motor. This will avoid
cavitation in slightly choppy water.
2) To prevent accidental damage to the fiberglass shaft, do not tighten this screw too much. Turn the steering
tension knob counterclockwise to reduce steering effort. To increase resistance, turn the steering tension
knob clockwise.
11
