PM-OA-16T PM-OA-20T
DBATTERY INSTALLATION
1. To dismantle the battery, follow the steps in the "Installing the batteries" section.
M.ASSEMBLY OF ACCESSORIES
1. Attach the harness from the sprayer kit to the holes so that the shorter part of the cushion strap is on the top
of the tank and the longer part of the strap is on the bottom of the tank.
2. Check that the 5 amp fuse is installed in the fuse cap. If the fuse is missing, the sprayer will not
start. The fuse holder is located on the underside of the sprayer. The fuse holder
(4) is shown in the figure in the section "Spraying work".
5A fuse
3. Connect the appropriate lance to the gun according to needs of use. Remember to place the
sealing O-ring on the lance cap. The o-rings are included in the enclosed sprayer kit.
4. Install the appropriate nozzle depending on the type of spraying performed. The set includes
many types of nozzles and fittings that can be freely combined. Before using the sprayer, it is
advisable to practice spraying techniques, which can be practiced in advance with clean water.
5. There is a fluid filter in the center of the sprayer tank. Remember to check the filter and clean it regularly.
Do not use the sprayer without the filter!
6. Fill the tank with the liquid. The liquid must not be too thick as it will not be able to be pumped
properly through the diaphragm pump system. This will reduce the spray range.
14
