DETAIL B
DETAIL A
DETAIL C
PowerMate
®
Operation Manua
l
SCREW ASSEMBLY M-1, M-2B
PN 300550

PARTS LIST
DESCRIPTION
PART No.ITEM
BRAKE CAP M-SERIES
1004501
WASHER THRUST BRONZE .0600508402
WASHER THRUST STEEL 1/2".090
0501403
WASHER RETAINER1509404
BRAKE SPRING
0508005
WASHER TOP BRAKE DRIVE0508206
ROLL PIN SPIROL 3/16"
0516807
WASHER THRUST STEEL 1/2"x .0300508108
THRUST WASHER
0501209
WASHER BOTTOM BRAKE DRIVE05085010
WASHER THRUST STEEL 1/2"x .060
05092011
BEARING RETAINER BAR30099012
PLATE WASHER 5/8"
05004013
URETHANE BUMPER
10070014
BALLNUT LOCKNUT 5/8 SCREW
05209015
SET SCREW 1/4-20NC x 5/1605055016
WASHER DISC SPRING 5/8"
050830B17
BALLNUT 5/8"050170C18
DRIVE SCREW 5/8"102040C
19
WASHER 5/8"
05185020
COUPLING COVER WITH SPLINE
30084221
BOLT 1/4-20NC
05064022
LOCK NUT 1/4-20NC
05061023
A
C
B
Ballnut Bracket on Outer Frame
Concave this side
(Assembly to Inner/Outer Frame)
Top Support on Inner Frame
18
22 1 2 23 4
5
8 9
8 10 2
11
2
12
11
9
11 13
14
13 23
16
17
21
7
19 20 14
6
19
15
16
7
PN 010520 Rev.E
Eng. 05/ 08/ 14
4.07
