PowerMate
®
Operation Manua
l
POWERMATE
®
M-SERIES WIRING DIAGRAM
301197
301198
301410
301420
090710 for M-1
090720 for M-2
Grommet
Splash
Guard
Stair Climber
Load Down
Push Button
Switch
PN 050210
Stair Climber
Load Up Push
Button Switch
PN 050210
Stair
Climber
Motor
PN 050860D
Charger
Plug
PN 050393
Fuse 10A
PN 051705
Controller
Unit
PN 052810
Circuit
Breaker/
Power
Disconnect
PN 051364
Battery
12V 32MAH
Sealed Dryfit
PN 051310
White Wire
Buzzer PN 301522
Fuse
Holder
PN 052690
Fr
o
m
Fu
s
e
T
o
B
a
t
t
e
r
y
-
301225
301223
301224
PN 010690 Rev.E1
Eng. 03/ 31/ 16
Sheet 1 of 2
5.08
