Powermate M-2C User Manual

PowerMate
®
Operation Manua
l
BRAKE ASSEMBLY KIT
PN 400150

PARTS LIST
DESCRIPTION
PART No.
QTY
ITEM
BEARING THRUST STEEL
05012011
WASHER THRUST STEEL 1/2".090
05014012
BRAKE SPRING
05080013
WASHER THRUST STEEL 1/2"x .03005081024
WASHER TOP BRAKE DRIVE
0508201
5
WASHER THRUST BRONZE .060050840
4
6
WASHER BOTTOM BRAKE DRIVE
0508501
7
WASHER THRUST STEEL 1/2"x .060
05092018
ROLL PIN SPIROL 3/16"x 1 1/8"05168019
WASHER RETAINER
150940110
PN 010590 Rev.E1
Eng. 03/ 09/ 16
4.09
The Roll Pin can be found here
under the Brake Spring.
BRAKE ASSEMBLY KIT
(as it is packaged)
6
2
6
10
3
9
5
4
1
4
7
6
8
6
