Powermate PMD5000s - Control Panel

OPERATING THE DIESEL GENERATOR
1-4.2 control panel
Single phase Control Panel
Three Phase Control Panel
Low oil protection
indicating lamp (12V)
Voltmeter
99T1-300V
2P support for
breaker
Fuse10 A
Red wire
holder (107)
Black wire
holder (107)
Bolt to the
grounded
Socket SCHUKO
230V 16A
Socket 2P+T
CEE 230V 16A
Electric start switch
Connector
7 contacts
Low oil protection
indicating lamp (12V)
Voltmeter
99T1-300V
2P support for
breaker
Fuse10 A
Red wire
holder (107)
Black wire
holder (107)
Bolt to the
grounded
Socket 2P+T
400V 16A
Socket 2P+T
CEE 230V 16A
Electric start switch
Connector
7 contacts
7
