7
Main materials
Headstock body Cast iron
Tailstock body Cast iron
Bed Cast iron
Tool rest Ductile iron, FCD45
Tool rest base Cast iron
Spindle S45S
Tailstock quill S45C
Face plate Cast iron
Dimensions
Overall size
assembled
LxWxH
Lathe only 52 x 24 x 18 in. (1321 x 610 x 457 mm)
Lathe with optional stand at highest position
52 x 25 x 48.5 in. (1321 x 635 x 1232 mm)
Lathe with optional stand at lowest position
52 x 25 x 38 in. (1321 x 635 x 965 mm)
Distance floor to spindle centerline, lathe on optional stand
(adjustable using levelers)
34~44-1/2 in. (864~1130 mm)
Bed gap 1-3/4 in. (45 mm)
Bed width 7 in. (178 mm)
Shipping dimensions
LxWxH
Lathe 870 x 480 x 580 mm (33.25 x 18.9 x 22.83 in.)
Stand (optional) 650 x 700 x 350 mm (25.59 x 27.56 x 13.78 in.)
Bed extension (optional) 300 x 350 x 200 mm (11.81 x 13.78 x 7.84 in.)
Weights
Lathe
Net weight 183 lbs. (83 kg)
Shipping weight 205.7 lbs. (93.5 kg)
Stand (optional)
Net weight 55 lbs. (25 kg)
Shipping weight 63.8 lbs. (29 kg)
13-in. Bed extension
(optional)
Net weight 29 lbs. (13 kg)
Shipping weight 30.8 lbs. (14 kg)
1
Subject to local/national electrical codes.
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
3
Recommended loading information; does not encompass all types of outboard activity. CAUTION: If you suspect a
workpiece could result in overweighting of the spindle or instability of the lathe, do NOT attempt to use it.
L = length, W = width, H = height
Items listed as “optional” are purchased separately.
The specifications in this manual were current at time of publication, but because of our policy of continuous
improvement, Powermatic reserves the right to change specifications at any time and without prior notice, without
incurring obligations.
