Powermatic PM2014 - Specifications

6
4.0 Specifications
Table 1
Model number
PM2014
Stock numbers
Lathe 1792014
Stand (optional accessory) 1792014S
Motor and Electricals
Motor
Type Totally-enclosed, fan-cooled
Horsepower 1 HP
Motor phase 3 PH
Motor voltage 230 V
Cycle 60 Hz
Motor speed 1720 RPM
Listed FLA (full load amps) 3 A
Input power requirements 1-phase, 120-volt
Drive system Poly V belt, E-type inverter drive, 3-step pulley
Operating switch Remote with magnetic base
VFD input amperage 13A, 1PH
VFD output to motor 3A (3PH)
Power cord and plug SJT 3x14AWG 300V, 7 ft., 5-15P
Remote switch cord AWM 24AWG 300V, 6-1/2 ft.
Recommended circuit size
1
15 A
Sound emission without load
2
75 dB at 20 inches (508mm) from motor
Capacities
Working distance between centers
19-1/4 in. (489mm) stop bolt installed
20-1/4 in. (514.4mm), stop bolt removed
Maximum distance between spindle face and tailstock quill 23 in. (584 mm), stop bolt removed
Working distance between centers with 13” optional bed
extension mounted
32-1/4 in. (819mm) with stop bolts installed
Inboard
turning
Swing over bed 14-1/4 in. (362 mm)
Swing over toolrest base 10-3/4 in. (273 mm)
Outboard
turning
Recommended maximum spindle load
3
356 kg (786 lbs.) at 100mm (4 in.) from spindle flange
Swing over optional 13in. bed extension in low
position
20-1/4 in. (514 mm)
Swing over toolrest base on optional 13in. bed
extension in low position
16-3/4 in. (425 mm)
Headstock and spindle
Spindle speeds (3 belt positions) Variable: 15~900, 30~1800, 60~3600 RPM
Spindle thread size 1-1/4 in. (31.75 mm) x 8 TPI, RH threads
Spindle direction Forward/reverse
Headstock spindle taper #2 Morse
Hole through headstock spindle, diameter 3/8 in. (9.5 mm)
Indexing 24 positions (15° workpiece rotations), positive locking
Faceplate diameter 3 in. (76.2 mm)
Tailstock
Tailstock quill taper #2 Morse
Hole through tailstock quill, diameter 3/8 in. (9.5 mm)
Tailstock quill travel 4-1/4 in. (108 mm)
Tailstock quill thread ACME 5/8 in-11
Tool rest
Tool rest width 8 in. (204 mm)
Tool rest post diameter 1 in. (25.4 mm)
Tool rest locking Bushing
