PowerPeak FTM8317P - ASSEMBLY

THEPRODUCT

1. Computer
2. Leftandrighthandlebar
3. Leftandrightcolumn
4. Cover
5. Runningbelt
6. Adjustmentscrewforrunningbelt
7. Heightadjustment
8. Framerunningbelt
9. Framefront
10.Safetykey





ASSEMBLY

Inordertofamiliariseyourselfwiththepartsofthedevice,weadviseyoutostudytheoverviewpicture
andthepartslistcarefullybeforeyoustartassembly.Placeallthepartsonthefloorandremoveall
packagingmaterials.














No. Description Quantity No. Description Quantity
1 Mainframe 1 41 BoltM8*16 12
14 Leftcoverhandle 1 60 Washer 12
15 Rightcoverhandle 1 56 ScrewSt4.2*12 14
88 Lowercoverleft 1 12 Allenwrench 1
89 Lowercoverright 1 11 Wrench/screwdriver 1
75 Safetykey 1

 





