powersoft Duecanali Series User Manual


LED Charts
  Type  
2
POWER 
keep pressed for
3 seconds
Toggle

3
CALL  press

Armonía workspace
4
SOFT
RESET
1

keep pressed for
3 seconds
Reset network parameters to
factory default
5
HARD
RESET
1

keep pressed for
3 seconds

6
CHECK 
keep pressed for
3 seconds
Start the self-checking

7
CH1
2

turn
counter-clockwise

the signal on channel 1
CH2
2

turn
counter-clockwise

the signal on channel 2

1. Keep pressed both the SOFT RESET button and the HARD RESET button for at least 3 sec-
onds to completely reset the amplier to its factory default conguration (this won’t delete
any preset stored in the internal memory).
2. The potentiometer is in series with the remote level control so it can be used to limit the
output volume regardless to any remote adjustment.
* Press again to resume normal operations
Control Panel
Color Signal Metering
Warnings
 
ORANGE
Clipping

— —
YELLOW -6dB
SOLID ON
Thermal warning

FLASHING 
GREEN -12dB — —
GREEN -24dB — —
GREEN -60dB
SOLID ON Signal presence
BLINKING Channel muted
GREEN — SOLID ON Channel ready
RED — SOLID ON Channel fault
1
1

LED Bars, signal metering
8
Color Name

 Power On
GREEN POWER ON
—
SOLID ON
ORANGE STANDBY SOLID ON
—
ORANGE AUTO STANDBY BLINKING
—
ORANGE ERROR CODE BLINK COUNTER
—

1
Self Check
6
System OK.
Power supply fault
AC Mains voltage
out of range
(over/under voltage)
PSU temperature
out of range
Fan Error
Channel#
Output Waveform
non-conformity
Channel#
Temperature
out of range
Channel#
Output current measurement
non-conformity
1
1. An 8Ω dummy load is needed to measure the output current. If the dummy
load is not applied the system reports a fault.
 Timings 
FLASHING
100 ms ON
900 ms OFF
BLINKING
500 ms ON
500 ms OFF
 Timings 
FLASHING
100 ms ON
400 ms OFF
FAST BLINKING
100 ms ON
100 ms OFF
BLINKING
500 ms ON
500 ms OFF
Color Name
Warnings
Lightning 
ORANGE
LIMIT
FLASHING Breaker Save Enabled
SOLID ON Breaker Save limiting power draw
YELLOW
TEMP SOLID ON
Thermal warning
Thermal protection engaged
ORANGE
CHECK
SOLID ON System self checking
BLINKING Self check completed
FAST BLINKING Self Check Unavailable
GREEN
REMOTE
SOLID ON Connected to Armonía Pro Audio
OFF Not connected to Armonía Pro Audio
GREEN
POWER ON
SOLID ON System ready
OFF System off
GREEN
MAINS
SOLID ON
AC mains voltage within the operating
range
OFF Undervoltage
FLASHING Over/Undervoltage Warning
FAST BLINKING Overvoltage
BLINKING Mains FUSES blown
RED
ALARM SOLID ON
PSU fault
1
OR Critical Faults
1
Red LED lights on in case of any kind of PSU fault that prevents normal operating.
LED Bar, system status
9
