M SERIES | SERVICE MANUAL
M Series has an internal jumper with a Faston to change
the operating voltage from 115V to 230V. (Fig. 29)
9. Changing the operating voltage:
(Fig. 29)
Move the faston to change the operating voltage as
indicated on the PCB as portrayed in (Fig. 30, 31)
(Fig. 30)
(Fig. 31)
