QUATTROCANALI | SERVICE MANUAL
5.1.6 Quattrocanali Rear Panel Introduction
A
AC Mains Connector
B
Air Vent
C
Output Connector
D
Line input Connector
E
Remote Levels Connector
F
Remote On/Off
G
Alarm Connector
H
Dante™ Port (DSP+D version only)
I
Ethernet Port
J
System Conguration Dip Switches
K
CH1, CH2 Output Conguration Dip Switches
L
CH3, CH4 Output Conguration Dip Switches
5.1.7 Duecanali Rear Panel Introduction
GF
K J I H
E
DB CA
A
AC Mains Connector
B
Air Vent
C
Output Connector
D
Line input Connector
E
Remote Levels Connector
F
Remote On/Off
G
Alarm Connector
H
Dante™ Port (DSP+D version only)
I
Ethernet Port
J
System Conguration Dip Switches
K
CH1, CH2 Output Conguration Dip Switches
