QUATTROCANALI | SERVICE MANUAL
5.2.4 DSP+DANTE Board Layout
Colour Description
Audio Control Section
DANTE Section
DANTE ETH Port
DSP ETH Port
Layout
Colour Description
Audio Control Section
DSP Processor
DSP ETH Port
Layout
5.2.5 CONTROL Board Layout
DSP+D Board (Old Version)
DSP+D Board (New Version)
