QUATTROCANALI | SERVICE MANUAL
7.4 Internal LEDs Checks - DSP+D Board - Normal Operating Conditions
Make sure that the plug is correctly inserted in the ETH Port.
Colour Status LED Action
A
RED
OFF SYS None
B
GREEN
ON SYS None
C
OFF ERR None
D
OFF ERR None
E
OFF CTR None
F
OFF CTR None
G
RED
OFF SYN None
H
GREEN
OFF SYN None
ON SYS
Check Standby LED
Troubleshooting table -
Point 7 and DANTE FW
Colour Status LED Action
I
ORANGE
BLINKING K None
J
GREEN
BLINKING K None
K
ORANGE
OFF K None
L
ORANGE
ON K None
ALL OFF
Check Standby LED
Troubleshooting table -
Point 7
Colour Status LED Action
M
ORANGE
ON 14V None
N
GREEN
ON 5V None
O
GREEN
ON 3.3VD None
P
ORANGE
ON +12V None
Q
ORANGE
ON -12V None
OFF 14V Check Standby LED
Troubleshooting table -
Point 7 and DANTE FW
OFF 3.3VD
Check the “Troubleshooting LED Error” table for further reference
BA FEDC G H
J
I
L
K
ON P QM
