powersoft Quattrocanali 4804

INDEX
60
QUATTROCANALI | SERVICE MANUAL
QUATTRO
4804
2404
1204
SMD01094.R
SMD01095.R
100-
240V
ON None None
U1 pin 4
(192KHz
master
clock
CH1-2)
Grounded on amplier
chassis
TEK00013
QUATTRO
4804
2404
1204
SMD01094.R
SMD01095.R
100-
240V
ON None None
U1 pin 10
(192KHz
master
clock
CH3-4)
Grounded on amplier
chassis
TEK00014
QUATTRO
4804
2404
1204
SMD01094.R
SMD01095.R
100-
240V
ON None None
OUT +
CH1
Grounded on amplier
chassis (Swicthing
Frequency Output
Residual)
TEK00015
QUATTRO
4804
2404
1204
SMD01094.R
SMD01095.R
100-
240V
ON
Sine
1KHz
0.5Vrms
8 ohm x
channel
OUT +
CH1
Grounded on amplier
chassis (Audio Output)
TEK00016
