INDEX
4
T-SERIES | SERVICE MANUAL
T-Series Service Analysis
A. Analysis and Solution
1 Main Board Refer to Chap. 7.2 & 7.3, check if PSU or AMP Section LEDs normal.
Refer to Chap. 6.3 to replace Main Board if required.
2 DSP Board Refer to Chap. 7.4, check if LEDs normal. Refer to Chap. 6.4 to replace DSP-D Board if required.
3 Front Board Refer to Chap. 6.5 to replace Front Board if required.
4 Rear Board Refer to Chap. 6.6 to replace Rear Board if required.
5 Flat Cables Refer to Chap. 6.3 & 6.4, to remove & replace if required.
6 Fans Refer to Chap. 7.5, check Fan in Working Condition. Refer to Chap. 6.2 to replace if required.
7 Opened Chassis Refer to Chap. 6.1 & to open Chassis.
8 Fuses Refer to Chap. 7.6, check Fuse & replace if required.
9 Mech Damage / Loose
Components Inside
Refer to Chap. 6.1, remove Amplier Cover to inspect interior & tighten back if possible.
10 Temperature Sensor Remove and clean air lters and perform Reset Procedure.
11 IP Address Refer to Chap. 12, check via the Front Panel Menu.
Refer to Chap. 13, connect Amplier to ArmoniaPlus to verify.
12 Dante Failsafe Mode Refer to Chap. 10.4 for Verifying & Chap. 10.5 for Recovery.
13 Firmware Checking Refer to Chap. 13 & carry out Firmware Update.
14 Dante Firmware Update Refer to Chap. 14 & carry out Firmware Update.
13 Resetting the IP Address via Front
Panel Menu
14 Checking of the Firmware using
ArmonìaPlus 1.3
15 Updating of the Firmware using
Dante Controller
16 T-Series Hardware Composition Part
Number
17 “Golden Sample” for Authorize
Service Center for Troubleshooting
18 Flowcharts For Repair Rev2.0
19 Replacement Parts
20 T-Series Spare Parts Rev. 5
21 Location to Paste the Anti-Tamper
Label after Repaired
22 Location to Paste the ASC
Replacement Mark after Repaired
To Next Page
