T-SERIES | SERVICE MANUAL
T-Series Main Board Spare Parts Rev. 2
Part
Number
Description
Order
to
Reference
Prime
Manufactured
Reference MPN
code
Qty Location
FU000026 FUSE 10A 250VDC T/LAG (5x20mm) Online www.octopart.com LITTELFUSE 215010.MXP 2 F1000-F1001-F3000-F3001
FU000038 FUSE CARTRIDGE 15A (6x32mm) Online www.octopart.com VISHAY 326015.MXP ?
F100 (PF00H471/PF00H475/
PF00H476/PF00H477)
FU000039 FUSE CARTRIDGE 10A (6x32mm) Online www.octopart.com LITTELFUSE 326010.MXP ? F100 (PF00H472/PF00H474)
IC000131 Step-Up/Down/Inverting switch Online www.octopart.com ON-SEMICONDUCTOR MC33063AP1G 1 U304
ICS00414 Si8234BB-D-IS1 4.0 AMP Online www.octopart.com SILICON LABORATORIES Si8234BB-DIS1 1 U1007-U2007-U3007-U4007
IS000082.XX ISL Hi-Flow 160X32 SER300P th2 Powersoft WSP 2
IS000085.XX ISL Hi-Flow 88X32 SER_300P Powersoft WSP 2
MO000039 FDH45N50F___________|TO247____ Online www.octopart.com INFINEON FDH45N50F-F133 2
Q1000-Q1003-Q2000-Q2003-
Q3000-Q3003-Q4000-Q4003
MO000048 IXTH48N65X2_________|TO247 Online www.octopart.com IXYS IXTH48N65X2 2 Q102-Q103-Q202-Q203
MOS00034 FCB20N60TM__________|D2PAK Online www.octopart.com FAIRCHILD FCB20N60TM ? Q100-Q200
Coming Soon
Note:
It’s required to attach the ASC Replacement Mark (ET001010.R) on the Repaired Main Board.
Refer to Chap. 22 and Paste the Label on the Recommended Location.
