powersoft T904 User Manual

T Series | 43
Front Panel
Rear Panel

T302 - T602 T304 - T604
7
CH1 (1+/-) | CH2 (2+/-) CH1 (1+/-) | CH2 (2+/-)
8
CH2 (1+/-) | n.c. (2+/-) CH3 (1+/-) | CH4 (2+/-)

T302 - T602 T304 - T604
11
Input 1 (XLR-F) Input 1 (XLR-F)
12
Input 1 (XLR-F) Input 2 (XLR-F)
13
Link 1 (XLR-M) Input 3 (XLR-F)
14
Link 2 (XLR-M) Input 4 (XLR-F)
AES3
9
AES3 IN (1GND/2+/3-)
10
AES3 OUT (1GND/2+/3-)
Network Connectors
15
ETH 1 (RJ45)
16
ETH 2 (RJ45)
USB Port
Speaker presets
Control Panel
1
CH1 - ON/STDBY (2s hold)
2
CH2 - COGWHEEL (2s hold)
3
CH3 (4 CH models) - Back
4
CH4 (4 CH models) - Apply
5

6
Value edit
Display
A
CH1
B
CH2
C
CH3 (4 CH models)
D
CH4 (4 CH models)
1 2
5 6
3 4
A B
C D
ground
mains
AC Mains Connector
IEC C19
T304 - T604 - T 904
T302 - T602 - T902
8 7
10 14 12 169 13 11 15
8 7
10
14 1612
9
13 1511
