3
PRODUCT SPECIFICATIONS:
BOX CONTENTS:
Input Voltage: 220 - 240 V ~ 50 Hz 0.6A
Power consumption: 65 W
Reverse current*: < 5 mA (no AC input)
Nominal output voltage: 6 V DC / 12 V DC / 12.8V DC
Nominal output current: 0.9 A / 4.0 A / 3.0 A
Charging voltage: 3 V / 7.4V for 6V battery, 14.5 V / 14.7V
for 12V battery, 14.5V for Lithium (12.8V
4-cells LiFePO4)
Charging current: 0.9 A ± 10 %, 4.0 A ± 10 %, 3.0 A ± 10 %
Battery type: 6V/12V lead-acid battery 12Ah - 120Ah
Lithium (12.8V 4-cells LiFePO4): with a
capacity of 8 - 50Ah
Housing protection type: IP 65 (dust-proof, water-proof)
Safety class: II
*Reverse current is the current used by the charging station battery, when
no mains current is connected.
Check the appliance and all accessories for damage immediately after
unpacking. Do not put a defective appliance or parts into operation.
• MB3906 Charger
• Clamps Cable
• Eyelet M6 Cable
• Instruction Manual
