PowerTech MP3743 - Box Contents; Product Diagram

1
BOX CONTENTS:
PRODUCT DIAGRAM:
1 x 12V/24V 30A MPPT Solar Charge Controller
1 x External Temperature Sensor
1 x User Guide
1 x App Guide
11
12
13
16
5 6 7 8 9 10
14
15
1
4
3
2
1 LCD Screen
2 Green Indicator LED
3 Red indicator LED
4 External Temperature Probe
5 Solar Positive Input
6 Solar Negative Input
7 Battery Positive Input
8 Battery Negative Input
9 Load Positive Output
10 Load Negative Output
11 Up Button
12 Menu Button
13 Enter Button
14 USB Outputs
15 Down Button
16 Ethernet Socket
