3
BASIC FUNCTIONS:
Settings Menu
If the display is o, tap the Menu button to turn it on.
Press & hold the Menu button to enter the settings menu, and tap the Menu
button again to cycle through each setting in the following order. Use the
Enter button to enter / save a setting.
# Menu Item Options
1 Battery Type Standard (STD) / Lithium (L) / AGM
(A)
2 WiFi On / O
3 Load Voltage Protection Cut O 10 – 11.5V (12V) – Default 10V
20 – 23V (24V) – Default 20V
4 Load Under Voltage Recovery 12 – 13V (12V) – Default 12.5V
24 – 26V (24V) – Default 25V
5 24 Mode On / O
6 Time Hours / Minutes
7 Load Timer On / O
When turned on, the next setting is
used to set the Load on time
Factory Reset
With the unit turned o, press & hold the Menu button & power up the
controller via the battery input. The screen will display FFFF to indicate all
settings have been factory reset.
