Appendix: Rear panel
The UPS rear panel description table and pictures are shown as below:
1000VA /1500VA/2000VA Standard
& 1000VA /1500VA Super charger model rear panel
2000VA Super charger model rear panel
No. Function(1000VA &1500VA&2000VA&3000VA)
1 AC Output
2 EPO / Dry in Communication Port
3 USB Port
4 AC Input
5 Dry out
6 SNMP slot
7 RS232
8 Modem/Network Surge Protection
9 Earth Line Port
