Powerware
®
9125 (9910 P30) Installation Guide for IBM
®
Applications S 164201544 Rev A Final 29-Jun-2004
P30 Installation Guide
Parts
Table 1. P30 Base Configuration
Part
Quantity IBM MN IBM FC IBM PN Powerware Description
1 P30 – 38P9297 103002728-3901 UPS 3000 VA, 2100W
1 – – 38P9308 103004081-3901 P30 Accessory Kit
Table 2. P30 Application Matrix
Part Application (Quantity)
IBM
MN
IBM
FC
IBM
PN
Powerware
PN
Description iSeries
Tower
IEC
iSeries
Tower
NEMA
pSeries
Tower
IEC
pSeries
Tower
NEMA
pSeries
Rack
WW
iSeries
Rack
WW
– 9830 38P9306 103003945-3901 Power Cord Kit 1 – 1 – 1 1
– 53P1963 103002841-3901 Left Rail – – – – 1 1
–
6630
53P1964
103002842-3901 Right Rail – – – – 1 1
–
6
6
3
0
53P1965 103002843-3901 Rail Hardware – – – – 1 1
– – 97P5675 103004084-3901 P30 Rack Mounting Bracket
Kit
– – – – 1 1
– 6570 38P9301 103003920-3901 NEMA PowerPass
®
Distribution Module (PDM)
– 1 – 1 – –
– 2936* 97P3886 103003564 Relay Interface Card and
Cable (25 ft/7.6m) Kit
1 1 – – – 1
*Maximum: One FC 2934 or 2936 per P30 UPS.
NOTE IEC: IEC Countries (e.g., UK, Italy, etc.); NEMA: NEMA Countries (e.g. U.S. and Canada); WW: Worldwide
Table 3. P30 Options Matrix
Part Application (Quantity)
IBM
MN
IBM
FC
IBM
PN
Powerware
PN
Description iSeries
Tower
IEC
iSeries
Tower
NEMA
pSeries
Tower
IEC
pSeries
Tower
NEMA
pSeries
Rack
WW
iSeries
Rack
WW
– 2934* 53P4619 103002974-5501 ConnectUPS -X
Web/SNMP/xHub Card
™
– – Min: 0, Max: 1 –
– 2938 38P9307 103003637-5501 Environmental Monitoring
Probe (EMP) and CAT 5 Cable
(6 ft/1.8m) Kit
– – Min: 0, Max: 1 Co-requisite:
FC 2934
–
– 6640 38P9299 103002837-3901 Extended Battery Module
(EBM)
Min: 0, Max: 4
– – 38P9310 103004082-3901 EBM Accessory Kit 1 per FC 6640
*Maximum: One FC 2934 or 2936 per P30 UPS.
NOTE IEC: IEC Countries (e.g., UK, Italy, etc.); NEMA: NEMA Countries (e.g. U.S. and Canada); WW: Worldwide
