P30 Installation Guide
3
Powerware
®
9125 (9910 P30) Installation Guide for IBM
®
Applications S 164201544 Rev A Final 29-Jun-2004
Table 9. Left Rail Kit (53P1963)
Quantity Powerware PN Description
1 157604171-001 Left Fixed Mounting Rail Assembly
1 157604171-003 Rear Support Rail
1 157604172-001 Rear Hold-Down Bracket
3 180400027-400 #10 Split Lock Washer
3 180500081-001 #10-32 Wing Nut
3 44700006 #10 Flat Washer
Table 10. Right Rail Kit (53P1964)
Quantity Powerware PN Description
1 157604171-002 Right Fixed Mounting Rail Assembly
1 157604171-003 Rear Support Rail
1 157604172-001 Rear Hold-Down Bracket
3 180400027-400 #10 Split Lock Washer
3 180500081-001 #10-32 Wing Nut
3 44700006 #10 Flat Washer
Setup and Installation
The Powerware 9125 P30 UPS is designed for flexible configurations and can be installed in a
rack, as a standalone cabinet, or in a tower configuration.
NOTE For UPS rack installations: If the UPS is pre-installed in an IBM rack, continue to
“Power Cord Connections” on page 12. If you are installing the UPS in an IBM iSeries (0550 or
0551 types) or pSeries (7014 type) rack, continue to the following section, “Rack-Mount Setup.” If
you have another type of rack, contact your service representative (see page 20).
NOTE For UPS standalone cabinet or tower installations: Continue to “Tower Setup” on
page 7 to begin the UPS setup.
Rack-Mount Setup
The UPS can be installed in 19-inch racks and needs only 2U of valuable rack space.
NOTE Mounting rails are required for each individual cabinet.
NOTE The UPS and any optional cabinets MUST be installed at the bottom of the rack. If placed
in a rack with existing equipment, the rack must be reconfigured to allow the UPS installation at
the bottom of the rack.
Each UPS and EBM requires one (1) of each item in the following list:
쑺 Left rail
쑺 Right rail
쑺 Rail hardware kit
쑺 Rack mounting bracket kit
