Powerware 9330 - System Configurations

xiv
Powerware 9330 (10 kVA--40 kVA) Installation and Operation
164201300 REV. G 061502
UPS
CABINET
BATTERY
CABINET
OPTIONS
CABINET
Typical Powerware 9330 (25 kVA---40 kVA) UPS System
System C onfigurations
These UPS system configurations are possible:
· Single Module UPS with integral battery
· Single Module UPS with integral battery and optional options cabinet
· Single Module UPS with integral battery and optional battery cabinet
· Single Module UPS with integral battery, optional battery cabinet, and optional
options cabinet
· Single Module UPS with remote battery
· Single Module UPS with remote battery and optional options cabinet
