Powerwerx DB-750X - Page 45

40
DB-750X
13
Menu Quick Reference List
13
Menu Name Default Page Function Settings
35 SCAN M MEM 26 PRIORITY CHANNEL SCAN MEN, MSN
36 SHIFT 600 26 OFFSET FREQUENCY SETUP 0 – 100 MHz
37 DISPLAY FREQ 26 DISPLAY MODE SETUP FREQ, CH, NAME
38 REPLOCK OFF 27 BUSY CHANNEL LOCKOUT RLORP, RLOBU, OFF
39 DTMF ID 001 27 RADIO'S DTMF SELF ID ENQUIRY
40 5TON ID 12345 27 5TONE SELF ID ENQUIRY
41 TOT 2 MIN 27 TOT (TIME-OUT TIMER) 1-30 MIN
42 VFOTR OFF 28 VFO FREQUENCY LINKAGE ON, OFF
43 WIDNAR NARROW 28 WIDE/NARROW BAND WIDE (25 kHz), MIDDLE (20 kHz), NARROW (12.5 kHz)
44 X-RPT -- 28 CROSS BAND REPEAT X-RPT, XSTART
45 LDC RED 1 28 LCD BACKLIGHT RED
46 LCD GRN 32 28 LCD BACKLIGHT GRN
47 LCD BLU 32 28 LCD BACKLIGHT BLU
48 DIMMER 32 29 KEYPAD BACKLIGHT BRIGHTNESS - MICROPHONE BRIGHTNESS – 32 LEVELS
49 NOTE -- 29 CALLING RECORD RECORD THE LAST 16 CALLS
50 AM ON 29 AM FUNCTION ON, OFF
51 AUT AM AUTO 29 AUTOMATIC AM FUNCTION ON, OFF
52 VSPCONT IN 29 VHF EXTERNAL SPEAKER PORT INT, EXT SP1, SP2
53 BP-VOL LOW 30 BEEP VOLUME CONTROL LOW, HIGH
54 TALK OFF 30 TALK AROUND
55 HND SPK MSPKOFF 30 MICROPHONE SPEAKER HSPKOFF, HSPKON, MSPKOFF
56 BAK OFF 33 MAIN BANK SET (BANKS – SET LEFT / RIGHT SIDE) OFF, A, B, C, D, E, F, G, H, I, J
57 BALK OFF 33 BANK LINKING ON/OFF
58 BLK A OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF (*Menu 58~67 will not appear until menus 56 & 57 are activated)
59 BLK B OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
60 BLK C OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
61 BLK D OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
62 BLK E OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
63 BLK F OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
64 BLK G OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
65 BLK H OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
66 BLK I OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
67 BLK J OFF* 33 ENABLE LINK TO THE MAIN BANK SET ON/OFF
68 PASS OFF 30 Enter a PASSWORD
