Powerwinch
712, 712-S, & 912 Trailer Winch
Pulley block can increase the pulling capacity approximately 55%.
1. Place two screws through one tear drop plate
and hold in place.
2. Slide a bushing over each screw.
3. Slide pulley wheel and hook over bushings as
4. Wrap cable around pulley.
5. Place second tear drop plate over screws and
secure using washers and nuts provided.
6. Mount an eyebolt next to winch. Eyebolt
should be mounted as close to winch as
possible.
ASSEMBLING PULLEY BLOCK
1. With cable threaded through block, hook pulley block to eye on bow.
2. Power out cable and attach cable hook to eyebolt next to winch.
3. Power in cable.
DOUBLE LINING WINCH
Only included with P77712 and P77912
pw915014
PW912002
12” minimum
Level
Bow
Eye
Pulley Block
Eye Bolt
Nut & Washer (x2)
Hook
Pulley
Side Plate
Side Plate
Cable
Bushing (x2)
Screw (x2)
