6
LCD display
Item
Description
1
PV voltage / Output power
2
Battery voltage / Charging current
3
Working mode / Temperature
4
Protection mode
Working mode
3. 0
Night mode, no charging
4. 0
MPPT mode
7. 0
Absorption mode
8. 0
Floating mode
Operation

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the PowMr MPPT-60A and is the answer not in the manual?

PowMr MPPT-60A Specifications

General IconGeneral
Rated Charge Current60A
Battery Voltage12V/24V/36V/48V Auto
Max. Efficiency98%
MPPT Tracking Efficiency99%
Operating Temperature+55°C
ProtectionOver Temperature
CommunicationRS485
