CPx Range Users, Installation & Servicing Instructions Doc Ref M201 issue 2.9 Nov 2018.
MODEL Burner Type Gas Control
High Fire Low Fire
Burner Pressure Gas Rate Burner Pressure Gas Rate
mbar m/h mbar m/h
CPx30 BS1D MB405/2 3.4 3.45 1.5 2.11
CPx45 BS1D MB405/2 6.4 5.00 2.5 2.85
CPx60 BS2D MB407/2 5.8 6.89 2.5 4.32
CPx90 BS3D MB407/2 4.2 10.34 1.9 6.82
CPx120 BS3D MB407/2 6.0 13.47 2.6 8.61
CPx150 BS3D MB410/2 9.1 17. 23 3.3 10.02
CPx175 BS4D MB410/2 8.3 20.10 3.5 13.90
CPx200 RS5D MB410/2 6.9 22.99 4.1 16.15
CPx250 RS5D MB412/2 9.3 28.46 5.8 14.38
CPx300 RS34 MZ MBDLE415 tbc tbc tbc tbc
Riello Burner Settings - Natural Gas - Group H - G20 Net CV (Hi = 34.02MJ/m³)
Nominal Inlet Pressure = 20mbar
Minimum Inlet Pressure = 17.5mbar
Notes: CO2 values and Nett flue gas temperatures are given for guidance and measured values will depend on site conditions.
* Air Pressure Switch settings are given for guidance and measured values will depend on site conditions.
MODEL
Head
Setting
no.
Combustion Air
Air
Pressure
Switch*
Flue
Pressure
Switch*
Nominal CO2
(±0.5)
Nox Nett Flue Temp
High Fire Low Fire High Fire Low Fire High Fire Low Fire High Fire Low Fire
No. No. No. mbar Pa % % ppm ppm °C °C
CPx30 1 2.8 1.0 2.1 40 9.2 8.75 24.7 26.8 132 74
CPx45 4 6.0 1.0 2.7 20 8.7 9.1 23.5 29.4 171 75
CPx60 4 2.0 1.0 2.0 120 8.75 9.0 27.9 28.8 145 78
CPx90 1 1.3 0.25 3.0 110 8.8 9.3 27.5 33.2 154 92
CPx120 5 2.1 1.0 5.0 280 9.2 8.8 34.5 31.9 174 102
CPx150 7 5.0 1.1 5.0 220 9.3 9.2 29.5 35.5 165 82
CPx175 7 5.3 1.8 3.6 270 9.3 8.6 28.4 32.3 158 89
CPx200 0 (39) (22) 4.0 300 9.0 8.8 41.4 40.0 141
97
CPx250 10 (63) (30) 4.0 300 8.8 8.4 44.0 44.3 142 79
CPx300 tbc tbc tbc tbc tbc tbc tbc tbc tbc tbc tbc
