page no. 7 of 68
CPx Range Users, Installation & Servicing Instructions Doc Ref M201 issue 2.9 Nov 2018.
Model 30 45 60 90(gas) 90(oil) 120 150 175 200 250 300 360 440 590
Output
kW 30 45 60 90 90 120 150 175 200 250 290 366 440 586
Input (nett CV)
G20 Gas kW 32.6 48.9 65.2 97.8 n/a 130.4 163.0 190.2 217.4 271.7 315.2 399.0 479.6 638.7
35sec Oil kW 31.9 48.7 64.3 n/a 97.7 130.5 160.3 190.3 213.3 269.4 316.1 391.6 470.8 627
Old Powrmatic Reference CP 100 150 200 300 300 400 500 600 700 800 1000 1250 1500 2000
Thermal Efficiencies (Nett CV) % Min 91.5%
Airflow
Volume m
3
/s 0.97 0.86 1.01 2.11 1.50 2.30 3.15 3.36 3.84 4.49 5.76 6.49 7.88 10.5
Heads
UF / HF No. 2 2 3 3 3 4 4 4 4 4 4 4 8 8
Size mm 203 254 254 305 305
305/358 305/358
358 406 457 457 457 457 457
Throw UF / HF m 15 21 19 24 24 24 29 29 29 41 48 48 30 40
Fan Static
Standard Pa 188 222 270 250 200 180 185 290 250 140 150 300 300 300
Up-rated Pa 250 250 400 500 450 350 400 500 500 450 500 600 600 600
Electrics
Supply
Standard V/ph/Hz 230/1/50 400/3/50
Optional V/ph/Hz 400/3/50 230/1/50 n/a
Standard
Fan
Motor kW 0.55 0.55 1.1 1.5 1.4 1.4 3.0 4.0 4.0 4.0 7.5 11.0 11.0 15.0
Run amp 4.3 5.7 5.3 10.0 9.6 6.4 6.7 7.1 8.6 8.4 14.5 21.3 21.3 28.9
Start amp 8.1 17.1 16.1 25.5 28.1 12.4 23.45 23.0 19.7 28.2 50.1 127.2 127.2 182.4
Uprated
Fan (L.H.P.)
Motor kW 0.75 0.75 2.2 2.2 1.5 3.0 4.0 5.5 5.5 5.5 11.0 15.0 15.0 18.5
Run amp 5.3 5.3 12.6 12.6 9.2 6.3 8.3 11.0 11.0 11.0 21.6 28.9 28.0 35.0
Start amp 15.9 15.9 37.8 37.8 27.6 22.05 29.05 38.5 38.5 38.5 75.6 182.4 182.4 221.2
Fuel
Connection
Oil BSP/Rc ⅜” ⅜” ⅜” n/a ⅜” ⅜” ⅜” ⅜” ⅜” ⅜” ⅜” ⅜” ⅜” ½”
Gas BSP/Rc ½” ½” ¾” ¾” n/a ¾” 1” 1” 1” 1¼” 1¼” 1½” 1½” 1½”
Minimum
Inlet
Pressure
Nat Gas mbar 17.5 n/a 17.5
LPG mbar 37.0 n/a 37.0
Consumption
Standard
Outputs
Oil l/h 3.16 4.83 6.38 n/a 9.70 12.95 15.90 18.89 21.17 26.73 31.36 38.82 47.45 63.62
Nat Gas m
3
/h 3.45 5.17 6.89 10.34 n/a 13.79 17.23 20.11 22.99 28.73 33.33 41.41 50.61 67.86
LPG m
3
/h 1.34 1.98 2.64 4.01 n/a 5.31 6.64 7.72 8.84 11.00 12.84 16.00 19.56 26.23
Overall
Dimensions
UF Upright
Freeblowing
Height mm 2024 2072 2494 2585 2585 2821 2821 3054 3174 3307 3307 3657 4107 4407
Width mm 669 669 744 744 744 904 904 904 904 1104 1104 1260 1330 1330
Depth
(Excludes
burner)
mm 732 732 927 927 927 1200 1200 1399 1399 1599 1599 1915 2165 2715
Installation
Clearances
UF Upright
Freeblowing
Front mm 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Side mm 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Blank Side mm 150 150 150 150 150 150 150 150 150 150 150 n/a n/a n/a
Rear mm 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
1000 1000
Flue Diameter mm ø 125 125 150 150 150 150 175 175 175 200 200 250 300 300
Combustion Air Spigot mm ø 150 150 150 150 150 150 150 150 150 150 150 150 175 175
Maximum Combustion Duct Length * m 34 34 21 21 21 12 8 6 4 3 2 3 2 2
Noise Level (See Note Below) dB(A) 56 61 61 63 63 70 62 73 74 75 77 78 80 82
Nett Weight (See Note Below)
kg 168 173 231 241 241 341 386 530 530 556 556 1012 1380 1720
Model 30 45 60 90(gas) 90(oil) 120 150 175 200 250 300 360 440 590
* For extended combustion duct lengths please contact Powrmatic
Notes –
• Fuel consumption and output figures based upon nett calorific values as follows
- Class D light distillate fuel oil nett CV 36.28 MJ/l
- Natural gas (G20) nett CV 34.02 MJ/m³
- Propane (G31) nett CV 88.00 MJ/m³
• CPx heaters comply with the seasonal efficiency and NOx limits requirements of the Ecodesign regulation (EU) 2015/1188, Directive 2009/125/EC – Lot 21 Tier 1
• Air handling data is assessed at room ambient conditions
• Throw figures provide the distance to the point where the terminal velocity degrades to 0.25 m/s
• Overall vertical heater height include heads or extended heads where appropriate
• Standard height heads can be specified where site height is restricted
• Blank and louvred lower side panels are interchangeable
• Dimensions in table above refer to upright heaters only - for horizontal and counterflow heater dimensions refer to dimensions page
• Noise levels are applicable to standard UF models and are measured 5m from appliance and in free field conditions
• Motor kW, run and start amps apply to standard electrical supply as stated. For optional data contact sales office
• Nett weight figures apply to standard upright CPx heaters only
• It is the responsibility of the installing contractor to ensure that ductwork is correctly sized and balanced when installing a ducted unit.
Technical Specification
CPx
