20
IGNITION SYSTEM CHECK
1. Remove the spark plug and reattach it to the spark plug lead.
2. Turn ignition key to the “RUN” position. Slide the engine stop switch to the “Run” position.
Kick the start lever.
If the ignition system is operating properly, a blue spark should jump across the spark plug gap. If
there is no spark, take your machine to your Service center.
Performing the spark test improperly could be hazardous.
You could get a high voltage electrical shock if you are not familiar with this procedure.
Do not perform this check if you are not familiar with the procedure.
Do not point the spark plug near the spark plug hole during this test.
Do not do this test if you have a heart condition or wear a pacemaker.
Do not preform this test is any near any open fuel containers for near fuel which has spilled on
the ground, on the engine, or any part of the Dirt Bike.
COMPLAINT: Engine stalls
1. Make sure there is enough fuel in the fuel tank.
2. Check to see that the spark plug is not fouled. Remove the spark plug and clean it. Replace
it, if necessary.
3. Make sure the fuel valve is not clogged, and the fuel tank is not clogged, either.
4. Check the idle speed. If necessary, adjust it using a tachometer. The correct idle speed is
1500±150r/min.
5. Make sure the air filter is clean.
