PR electronics 2261 Product Manual

8 2261V103-UK
Order
Type
2261
Hardware programming
JP1 JP2 Output range MENU 4.3
OFF OFF
0...10 mA
0...20 mA
001
002
ON OFF
0...500 mV
0...1000 mV
003
004
OFF ON
0...5 V
0...10 V
005
006
Block diagram
2261
CPU
A / D
DC
PGA
D / A
Vreg
NPN
PNP
0...20
mA
3
2
A
v v
A
I+
V+
DC
10
9
8
5
7
mV
EEPROM
JP1 JP2
50 500
1
6
4
11
+
-
e
Supply + 24VDC
Supply gnd.
Input +
Sense
Sense
NC
Digital Input
+ 24 VDC
Input -
V Excitation +
V Excitation gnd.
Gnd.
I + V
Out
I
Out
V
Out
24 VDC
Spec.
V Out
R 68
