12 4225V100-UK
Accessories
4501 = Display / programming front
4511 = Modbus communication enabler
4512 = Bluetooth communication enabler
Note: The PR 4500 communication interfaces are approved and certified as an add-on component to the 4000 series of
devices. All technical characteristics are valid with the PR 4500 communication interface attached.
Electrical specifications
Environmental conditions:
Operating temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -20°C to +60°C
Storage temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -20°C to +85°C
Calibration temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20...28°C
Relative humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 95% RH (non-cond.)
Protection degree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IP20
Installation in pollution degree 2 & measurement / overvoltage category II.
Mechanical specifications:
Dimensions (HxWxD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109 x 23.5 x 104 mm
Dimensions (HxWxD) w/ 4501 / 451x . . . . . . . . . . . . . . . . . . . . . . . 109 x 23.5 x 116 / 131 mm
Weight approx., 4225A / 4225B / 4225C . . . . . . . . . . . . . . . . . . . . . 160 / 165 / 150 g
DIN rail type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DIN EN 60715 - 35 mm
Wire size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.13...2.08 mm
2
/ AWG 26...14 stranded wire
Screw terminal torque. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.5 Nm
Common electrical specifications:
Supply voltage, universal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21.6...253 VAC, 50...60 Hz
or 19.2...300 VDC
Protective fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400 mA SB / 250 VAC
Max. required power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 2.6 W
Max. power dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 2.1 W
Isolation voltage - test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.3 kVAC
Isolation voltage - working
Input to any. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250 VAC (reinforced)
Relay to relay, relay to analog . . . . . . . . . . . . . . . . . . . . . . . . . . . < 115 VAC (reinforced), > 115 VAC (basic)
NPN to analog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Isolated > 50 VDC
Push-Pull / PNP to analog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Shared ground with analog output
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PR 4500 communication interfaces
Signal dynamics, output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 bit
Signal / noise ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . > 60 dB
Response time (0...90%, 100...10%) . . . . . . . . . . . . . . . . . . . . . . . . ≤ 30 ms
Type Output
4225 1 analog output and 1 relay
2 relays
1 analog output and 1 frequency output
: A
: B
: C
