9106 - Product version 9106-002 11
Max. required power is the maximum power needed at terminals 31 and 32.
Max. power dissipation is the maximum power dissipated by the device.
If the 9106 is used with the 45xx, then add 40 mW to the max. power dissipation and 70 mW to the max. required power for each device
with the 45xx.
Isolation - test / working:
Input to any. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6 kVAC / 300 VAC reinforced isolation
Analog output to supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.6 kVAC / 300 VAC reinforced isolation
Status relay to supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5 kVAC / 150 VAC reinforced isolation
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Communication enabler 4511 /
Programming front 4501
Signal dynamics, input /output . . . . . . . . . . . . . . . . . . . . . . . . . . . Analog signal chain
SMART bi-directional communication frequency range . . . . . . . . . . . . . 0.5...7.5 kHz
Signal / noise ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . > 60 dB
Response time (0...90%, 100...10%) . . . . . . . . . . . . . . . . . . . . . . . . < 5 ms
Eect of supply voltage change on output (nom. 24 VDC) . . . . . . . . . . . < ±10 µA
Current input:
Measurement range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5...23 mA
2-wire transmitter supply (terminal 44...43 and 54...53):
9106x1xx (Uo=27.5 VDC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >16 V / 20 mA
9106x2xx (Uo=25.3 VDC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >15 V / 20 mA
Sensor error detection:
Loop break 4...20 mA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 1 mA
Input voltage drop:
Supplied unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 4 V @ 23 mA
Non-supplied unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 6 V @ 23 mA
EMC - immunity influence. . . . . . . . . . . . . . . . . . . . . . . . . < ±0.5% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst . . . . . . . . . . . . . . . . . . . . < ±1% of span
Accuracy values
Input type Absolute accuracy Temperature coecient
mA ≤ ±16 ≤ ±1.6 μA /
Type Description
Max. power
dissipation
Max. required
power
Passive input
9106x1Ax 1 ch. (Ex Uo 27.5 V) ≤ 0.8 W ≤ 1.1 W
9106x1Bx 2 ch. (Ex Uo 27.5 V) ≤ 1.2 W ≤ 1.9 W
9106B2Ax 1 ch. (Ex Uo 25.3 V) ≤ 0.8 W ≤ 1.1 W
9106x2Bx 2 ch. (Ex Uo 25.3 V) ≤ 1.2 W ≤ 1.9 W
Active input
9106x1Ax 1 ch. (Ex Uo 27.5 V) ≤ 1.1 W ≤ 1.1 W
9106x1Bx 2 ch. (Ex Uo 27.5 V) ≤ 1.9 W ≤ 1.9 W
9106x2Ax 1 ch. (Ex Uo 25.3 V) ≤ 1.1 W ≤ 1.1 W
9106x2Bx 2 ch. (Ex Uo 25.3 V) ≤ 1.9 W ≤ 1.9 W
