9106 - Product version 9106-002 13
Visualisation in 45xx of hardware / software error
Readout at hardware error
Error search Readout Cause
Communications test 45xx and 9106 NO.CO Connection error
EEprom error - check configuration FL.ER
Configuration error or CRC mismatch, recovery
configuration is loaded
User error II ! / II ! Loop limit exceeded
User error II ! / II ! Loop error
EEprom error - check configuration EE.ER / IE.ER Invalid configuration (CRC or data)
Hardware error SU.ER Supply error
Hardware error RA.ER RAM error
Hardware error FL.ER Flash error
Hardware error IN.ER Initialization error
Hardware error C1.ER Hardware error - channel 1
Hardware error C2.ER Hardware error - channel 2
Hardware error DE.ER General error
! All error indications in the display flash once per second. The help text explains the error.
In case of cable fault the backlight also flashes. This can be reset by pressing the 3 key.
Errors affecting both channels are shown as error on channel 1 - and the line showing channel 2 is blank.
Hardware error can be reset in two ways. Either step through the menus (if the other channel is to stay in
operation) or power cycle the device.
