PR electronics 9106 User Manual

54
53
52
51
44
43
42
41
44
43
42
41
COMMUNICATION FOUNDATION
Tx
-
+
-
12
11
14
13
mA
+
-
mA
+
-
COMMUNICATION FOUNDATION COMMUNICATION FOUNDATION
mA
+
mA
+
31
32
33
34
COMMUNICATION FOUNDATION
-
+
-
Tx
+
+
9106 - Product version 9106-002 7
Applications - 9106Axxx
Rail, supply +
Rail, supply -
Power rail
Status relay signal
Zone 2 & Cl. 1, Div. 2, gr. A-D
or Safe Area
Device status
Device status
Supply -
Supply +19.2...31.2 VDC
N.C.
No connection
No connection
Power connection:
Channel 2
Output signals:
Analog, 4...20 mA
Input signals:
Channel 1
2-wire
transmitter
Current
Passive 2-wire
Current
2-wire
transmitter
Same power rail as above
Channel 1
Channel 2
