9106QF01
LERBAKKEN 10, 8410 RØNDE DENMARK
Revision date:
2019-04-04
Version Revision
V5 R0
Prepared by:
PB
Page:
1/5
FM Installation drawing
For safe installation of 9106B the following must be observed. The module shall only be
installed by qualified personnel who are familiar with the national and international laws,
directives and standards that apply to this area.
Year of manufacture can be taken from the first two digits in the serial number.
For Installation in Div2/Zone2 the following must be observed.
The 4501 programming module is to be used solely with PRelectronics modules. It is important
that the module is undamaged and has not been altered or modified in any way. Only 4501
modules free of dust and moisture shall be installed.
9106Bab. HART Transparent Repeater
a: Barrier (1 = 27.5V barrier; 2 = 25.3V barrier)
b: Channels (A = Single; B = Double)
Supply terminal (31,32)
Voltage: 19.2 – 31.2VDC
Status Relay. terminal (33,34) Zone 2 installation
Voltage max: 125VAC / 110VDC 32VAC / 32VDC
Power max: 62,5VA / 32W 16 VA / 32 W
Current max: 0.5A AC / 0.3ADC 0.5A AC / 1ADC
Installation notes:
In Class I, Division 2 installations, the subject equipment shall be mounted within a too-secured
enclosure which is capable of accepting one or more of the Class I, Division 2 wiring methods
specified in the National Electrical Code (ANSI/NFPA 70), or Canadian Electrical Code (C22.1).
In Class I, Zone 2 installations, the subject equipment shall be mounted within a tool secured
enclosure which is capable of accepting one or more of the Class I, Zone 2 wiring methods specified
in the National Electrical Code (ANSI/NFPA 70)or or Canadian Electrical Code (C22.1). Where
installed in outdoor or potentially wet locations, the enclosure shall, at a minimum, meet the
requirements of IP54.
Install in environments rated Pollution Degree 2 or better; overvoltage category I or II.
The equipment shall be installed in an enclosure with a minimum ingress protection rating of IP54
unless the apparatus is intended to be afforded an equivalent degree of protection by location.
The module is galvanically isolated and does not require grounding.
Use 60 / 75 ºC copper conductors with wire size AWG: (26-14)
Warning: Substitution of components may impair intrinsic safety.
Warning: To prevent ignition of the explosive atmospheres, disconnect power before servicing and do
not separate connectors, install or remove module from Power Rail when energized and an explosive
gas mixture is present.
Warning: The Loop Supply and Current Input terminals for the same channel shall not be applied at
the same time. The wiring of unused terminals is not allowed.
FM Installation Drawing
9106 - Product version 9106-002 31
