9106QU01
LERBAKKEN 10, 8410 RØNDE DENMAR
Revision date:
2019-06-20
Version Revision
V1 R0
Prepared by:
PB
Page:
1/7
UL Installation drawing
For safe installation of the Process Control Equipment (
Associated Apparatus) 9106B the
following must be observed. The module shall only be installed by qualified personnel who
are familiar with the national and international laws, directives and standards that apply to
this area.
For Installation in Div2/Zone2 the following must be observed.
The 4501 programming module is to be used solely with PR electronics modules. It is important
that the module is undamaged and has not been altered or modified in any way. Only 4501
modules free of dust and moisture shall be installed.
9106B1A-U9: 1 channel HART
®-transparent repeater (27.5V Barrier)
9106B1B-U9: 2 channel HART
®-transparent repeater (27.5V Barrier)
9106B2A-U9: 1 channel HART
®-transparent repeater (25.3V Barrier)
9106B2B-U9: 2 channel HART
®-transparent repeater (25.3V Barrier)
Marking:
Proc. Cont. Eq. for Use in Haz. Loc.
Install in CL I DIV2 GP A-D T4 provide
IS circuits to CL I-III DIV 1 GP A-G
or CL I Zn2 Gp IIC T4 provides IS
E233311 circuits for CL I Zn0 Gp IIC/Zn20 Gp IIIC
Um=253V [Exia] Installation Drawing: 9106QU01
Standards:
UL 121201 NONINCENDIVE ELECTRICAL EQUIPMENT FOR USE IN CLASS I AND II,
DIVISION 2 AND CLASS III, DIVISIONS 1 AND 2 HAZARDOUS (CLASSIFIED) LOCATIONS
Edition 9 - Revision Date 2018/08/31
CSA C22.2 NO. 213 NONINCENDIVE ELECTRICAL EQUIPMENT FOR USE IN CLASS I
AND II, DIVISION 2 AND CLASS III, DIVISIONS 1 AND 2 HAZARDOUS (CLASSIFIED)
LOCATIONS- Edition 3 - Issue Date 2017/09/01
UL 913 STANDARD FOR INTRINSICALLY SAFE APPARATUS AND ASSOCIATED
APPARATUS FOR USE IN CLASS I, II, III, DIVISION 1, HAZARDOUS (CLASSIFIED)
LOCATIONS- Edition 8 - Revision Date 2015/10/16
CSA C22.2 NO. 60079-0 EXPLOSIVE ATMOSPHERES — PART 0: EQUIPMENT —
GENERAL REQUIREMENTS- Edition 3 - Issue Date 2015/10/01
CSA C22.2 NO. 60079-11:14 EXPLOSIVE ATMOSPHERES — PART 11: EQUIPMENT
PROTECTION BY INTRINSIC SAFETY “I”- Edition 2 - Issue Date 2014/02/01
UL Installation Drawing
36 9106 - Product version 9106-002
