9106QI01
LERBAKKEN 10, 8410 RØNDE DENMARK
Revision date:
2016-11-30
Version Revision
V5 R0
Prepared by:
PB
Page:
3/5
Hazardous area Non Hazardous area
Zone 0,1,2, 20, 21, 22 or Zone 2
9106B1A, 9106B1B, 9106B2A, 9106B2B
Ex input: External current source
CH1 (terminal 41,42)
CH2 (terminal 51,52)
U
o
: 0 V
I
o
: 0 mA
P
o
: 0 mW
U
i
: 30 V
I
i
: 120 mA
P
i
: 0.85 mA
C
i
: 2 nF
L
i.
0 μH
44
43
42
41
54
53
52
51
34
33
32
31
14
13
12
11
9106
4501
91 92 93 94 95
Power
Rail
CH1
CH2
+
+
_
_
-20 ≤Ta ≤ +60ºC
(terminal 11,12,13,14)
(terminal 31,32,33,34)
(terminal 91,92,93,94,95)
U
m
: 253 V, max. 400 Hz
9106 - Product version 9106-002 23
