CROSS SLIDE & SADDLE Fig 9
Dimensions in millimeters
Ref Description Part
1 Handle Z3440
2 Screw M10 Z3441
3 Lock screw M6×25 Z3442
4 Flange screw Z3443
5 Handwheel Z3444
6 Spring 5×1×12 Z3445
7 Steel ball 5 Z3446
8 Graduated collar Z3447
9 Ball bearing 51102 Z3448
10 Support ange Z3449
11 Socket head screw M6×20 Z3450
12 Leadscrew Z3451
13 Key 5×8 Z3452
14 Spacer Z3453
15 Roll pin 4×25 Z3454
16 Gear Z3455
17 Screw M6×8 Z3456
18 Bronze leadscrew nut Z3457
19 Socket head screw M6×16 Z3458
20 Socket head screw M10×30 Z3459
21 Taper pin 6×45 Z3460
22 Rubber wiper, LH Z3461
23 Socket head screw M10×45 Z3462
24 Saddle casting Z3463
25 Gib screw Z3464
Ref Description Part
26 Gib Z3465
27 Cross slide Z3466
28 Angle scale Z3467
29 T-nut Z3468
30 Pivot stud 4×80 Z3469
31 Cup Z3470
32 Socket head screw M8×16 Z3471
33 Oiler 6 Z3472
34 Saddle gib, front LH Z3473
35 Hex head bolt M8×20 Z3474
36a Filler plug Z3488
36 Saddle gib, front RH Z3475
37 Rubber wiper, RH Z3476
38 Wiper clamp plate Z3477
39 Screw M5×12 Z3478
40 Screw M8×25 Z3479
41 Nut M8 Z3480
42 Screw M8×25 Z3481
43 Back gib support Z3482
44 Gib Z3483
45 Wiper clamp plate Z3484
46 Rubber wiper Z3485
47 Screw M8×16 Z3486
48 Screw M6×12 Z3487
